STRAIGHT LINE RAZOR WIRE - BLADE LENGTH 10mm, 20mm, 15mm, 22mm, 65mm-GENERAL ANTI CLIMB FENCE TOP LINES
Straight line razor wire is made of blade type barbed wire straightened for easy and quick installation. It makes ideal anti-climbing fencing top lines for common metal wire fences. By electrifying the straight line razor wire, the security deterrent of the fence can be significantly increased.
Straight-line razor wires as fencing tops are often used for residential or lower-security areas, while crossed concertina wires are preferred for increasing fencing security in military bases, prisons, and high-security areas.
Razor blade wire includes spiral razor wire and straight razor wire.
Straight Razor Wire Hot dip Galvanized is suitable for offshore purpose.
Features: Corrosion resistance, anti-aging, weather resistance, etc.
The forms of corrosion resistance include electric galvanizing and hot dipped galvanizing.
Specification: The blade length, wire diameter, plate thickness can be custom made.
Straight line razor wire common sizes:
A1: Blade thickness: 0.5mm; core diameter: 2.5mm; blade length: 10mm; blade width: 13mm; blade distance: 26mm
A2: Blade thickness: 0.5mm; core diameter: 2.5mm; blade length: 20mm; blade width: 15mm; blade distance: 33mm
A3: Blade thickness: 0.5mm; core diameter: 2.5mm; blade length: 15mm; blade width: 15mm; blade distance: 33mm
A4: Blade thickness: 0.5mm; core diameter: 2.5mm; blade length: 22mm; blade width: 16mm; blade distance: 36mm
A5: Blade thickness: 0.6mm; core diameter: 2.5mm; blade length: 65mm; blade width: 22mm; blade distance: 102mm
Straight razor wire BTO-18 and BTO-22
CBT 65 Razor wire in straight lengths
Galvanized razor wire (3.6kg/roll) blade profile bt65
Razor wire cbt-65 - electro galvanized zinc
450mm diameter and 28 rings
Straight length 46.5 mt per roll after pull open
Standard covered length 7.5 mt
Packing: 3.6kg/roll 5roll/ctn
Straight Razor Wire offers beautiful, economical and practical fencing with good prevention effect, convenient construction and other excellent characteristics. It can be made into different crossed type in different diameter and widely used in high wall or fence tops.
Straight Razor Wires are popularly made with following razor wire profiles:
| Reference Number | Thickness | Wire Dia | Barb Length | Barb Width | Barb spacing |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5 | 28 | 15 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5 | 30 | 18 | 45±1 |
| CBT-60 | 0.5±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.5±0.05 | 2.5±0.1 | 65±2 | 32±1 | 100±2 |
Straight Razor Barbed Wire Packing: 5 rolls/carton or waterproof paper and bag.
Installation:
Straight razor wire is easy to install in straight lines, suitable for the tops of existing walls or fences.
Straight-line razor wire involves stretching razor wire in straight lines between posts or on top of fences. It's simpler to install than concertina wire, as it doesn't require the wire to be coiled or clipped in circles. The installation typically involves fixing brackets to posts or existing structures and then stringing the razor wire through these brackets.
